Téléchargez le livre : Automated Broad and Narrow Band Impedance Matching for RF and Microwave Circuits

Automated Broad and Narrow Band Impedance Matching for RF and Microwave Circuits



de

Éditeur :

Springer


Paru le : 2018-10-06



eBook Téléchargement , DRM LCP 🛈 DRM Adobe 🛈
Lecture en ligne (streaming)
94,94 €
Téléchargement immédiat
Dès validation de votre commande
Ajouter à ma liste d'envies
Image Louise Reader présentation

Louise Reader

Lisez ce titre sur l'application Louise Reader.

badge apple Application Louise Reader
badge Android Application Louise Reader
Description

This book presents a seamless and unified scheme for automating very complicated calculations required to design, evaluate performance characteristics of, and implement broadband and narrow band impedance matching sub-circuits.  The results of these automated calculations (the component values of the impedance matching sub-circuit) are formatted as text SPICE(Simulation Program with Integrated Circuit Emphasis) input netlists.  Readers then immediately can use any available SPICE simulator to measure the performance characteristics (DC response, transient response, frequency response, RMS power transferred from source to load, reflection coefficient  insertion and transmission loss, ans standing wave ratio – SWR).  The text SPICE netlist can be edited easily to fine-tune the performance characteristics, and perform design space exploration and “what-if” type of analyses.



Presents details of a coherent, logical and seamless scheme to design and measure the performance characteristics of both broad and narrow band impedance matching sub-circuits;
Relieves the designer from having to manually do complex, multi-step(therefore error-prone and time-consuming) calculations, especially those related to broadband impedance matching sub-circuit design;
Provides SPICE input netlists, which enable readers to use any available SPICE simulator to estimate the performance characteristics.
Pages
109 pages
Collection
n.c
Parution
2018-10-06
Marque
Springer
EAN papier
9783319990002
EAN PDF
9783319990019
Informations sur l'ebook
Nombre pages copiables
1
Nombre pages imprimables
10
Taille du fichier
2734 Ko
Ce livre est accessible aux handicaps Voir les informations sur l'accessibilité
Prix
94,94 €
EAN EPUB
9783319990019
Informations sur l'ebook
Nombre pages copiables
1
Nombre pages imprimables
10
Taille du fichier
6308 Ko
Ce livre est accessible aux handicaps Voir les informations sur l'accessibilité
Prix
94,94 €
